The belt-type floor mat die-cutting production line is a high-efficiency machine specifically designed for the die-cutting of floor mats. It integrates automatic feeding and waste removal functions, significantly improving production efficiency and product quality. Below is an introduction to its functions and features:
1. Automatic Feeding
Equipped with a belt conveyor system that automatically delivers raw materials to the die-cutting station, eliminating the need for manual intervention.
High feeding accuracy with adjustable settings to accommodate different materials and sizes, reducing material waste.
2. Automatic Die-Cutting
Utilizes a high-precision die-cutting mechanism suitable for processing complex patterns and shapes of floor mats.
3. Automatic Waste Removal
Features a waste removal system that automatically eliminates excess scrap and keeps the working area clean.
4. Finished Product Output
After die-cutting, the finished products are conveyed out via the belt system, facilitating connection with subsequent processes.

Model No.
ABC-1500
Max cutting force（can be customized）
150T
Press plate to table distance（can be customized）
95-270mm
Effective worktable area（can be customized）
1600*1400mm
